The Danish National Cryo-EM Facility

Aarhus Node. Small things can have a great impact

Images processed
4,160,000
Applications
626
Users
149

Figures are approximate

Cryogenic electron microscopy (cryo-EM) allows for collection of high resolution data from a range of samples including protein molecules, macromolecular complexes or cells.

In 2018 a grant of 30.8 mio DKK (4.7 mio USD) was allocated EMBION from the Ministry of Higher Education and Science - funded from 2015 call of the Danish Roadmap for Research Infrastrucutures. EMBION is a new cryo-EM consortium between Danish Universities (AU host and KU co-host). The National Cryo-EM Facility at AU started up medio 2019 using existing electron microscopes and facilities. Based on the grant a new high-end electron microscope was purchased: a Titan Krios 300 keV transmission electron microscope with a Bioquantum/K3 detector setup and a Micro-ED system. Installation of the new Titan Krios (Krios2) microscope finished in Q4 2020 and user access to the new microscope started Q1 2021. The official inauguration of EMBION was 12th October 2020.

EMBION is hosted by the Department of Molecular Biology and Genetics (MBG) at Aarhus University. All applications for instrument time, from Denmark and abroad, go through the EMBION portal.

Learn more about us

News

DKK 215 million from the Novo Nordisk Foundation for DANCEM

The grant establishes DANCEM, the Danish National CryoEM Infrastructure: a distributed national infrastructure built on EMBION at Aarhus University and the Core Facility for Integrated Bioimaging at the University of Copenhagen. It funds new state-of-the-art electron microscopes, IT upgrades and specialist staff, with a focus on cryo-electron tomography, and will be open to researchers from universities, hospitals and industry across Denmark and the Nordics.

Read the announcement (opens in a new tab)

Instruments

You can't innovate without the best instruments

01 / 06

Titan Krios G3i (300 keV)

  • 967 Bioquantum energy filter
  • K3 detector
  • Ceta-D detector
  • Single tilt stage
  • EPU/Tomo5/EPU-D automated data collection software
The Titan Krios G3i (300 keV)

02 / 06

Titan Krios 300 kV TEM

  • 967 Bioquantum special energy filter with full spectroscopy
  • K2 Summit detector
  • Orius 4K detector
  • US4000 4K detector
  • Volta Phase Plate
  • Cs corrector
  • Double tilt stage
  • EPU/SerialEM automated data collection software
The Titan Krios 300 kV TEM

03 / 06

Aquilos 2 Cryo FIB

  • EasyLift Cryo
  • iFLM
  • AutoTEM/MAPS 3/AMIRA software
  • Auto Slice and View 4 software
  • Integrated sputter coater and GIS system
  • CCD IR Camera
  • SE Detector (ET-SED)
  • ICE Detector
  • Beam deceleration function
The Aquilos 2 Cryo FIB

04 / 06

Tecnai Spirit 120 kV TEM

  • TWIN lens
  • Cryo-box
  • TemCam-F416 (4kx4k) TVIPS CMOS bottom mounted camera
  • Veleta (2kx2k) CCD side mounted camera
  • Leginon/Appion automated data collection pipeline
The Tecnai Spirit 120 kV TEM

05 / 06

Versa 3D Focused Ion Beam SEM

  • Cryo-stage for cryo FIB-SEM
  • Auto Slice and View
  • High vacuum mode: Everhart-Thornley Detector (ETD)
  • ESEM(gaseous)mode: Low-vacuum Detector (LVSED) and Gaseous detector (GSED)
  • vCD, 4-segment backscattered electron detector (BSED)
  • IR camera, Integrated Infra-Red inspection camera
The Versa 3D Focused Ion Beam SEM

06 / 06

Nova NanoSEM

  • EDAX EDS system, Energy Dispersive Spectroscopy
  • SED, Everhart Thornley secondary electron detector.
  • TLD-SE, in-lens secondary electron detector.
  • SS-BSED is a solid-state backscattered electron detector.
  • UHR low vacuum SED (Helix detector)
  • Low vacuum solid-state BSED (GAD)
  • IR camera, Integrated Infra-Red inspection camera
The Nova NanoSEM
The Titan Krios G3i (300 keV)

Titan Krios G3i (300 keV)

  • 967 Bioquantum energy filter
  • K3 detector
  • Ceta-D detector
  • Single tilt stage
  • EPU/Tomo5/EPU-D automated data collection software
The Titan Krios 300 kV TEM

Titan Krios 300 kV TEM

  • 967 Bioquantum special energy filter with full spectroscopy
  • K2 Summit detector
  • Orius 4K detector
  • US4000 4K detector
  • Volta Phase Plate
  • Cs corrector
  • Double tilt stage
  • EPU/SerialEM automated data collection software
The Aquilos 2 Cryo FIB

Aquilos 2 Cryo FIB

  • EasyLift Cryo
  • iFLM
  • AutoTEM/MAPS 3/AMIRA software
  • Auto Slice and View 4 software
  • Integrated sputter coater and GIS system
  • CCD IR Camera
  • SE Detector (ET-SED)
  • ICE Detector
  • Beam deceleration function
The Tecnai Spirit 120 kV TEM

Tecnai Spirit 120 kV TEM

  • TWIN lens
  • Cryo-box
  • TemCam-F416 (4kx4k) TVIPS CMOS bottom mounted camera
  • Veleta (2kx2k) CCD side mounted camera
  • Leginon/Appion automated data collection pipeline
The Versa 3D Focused Ion Beam SEM

Versa 3D Focused Ion Beam SEM

  • Cryo-stage for cryo FIB-SEM
  • Auto Slice and View
  • High vacuum mode: Everhart-Thornley Detector (ETD)
  • ESEM(gaseous)mode: Low-vacuum Detector (LVSED) and Gaseous detector (GSED)
  • vCD, 4-segment backscattered electron detector (BSED)
  • IR camera, Integrated Infra-Red inspection camera
The Nova NanoSEM

Nova NanoSEM

  • EDAX EDS system, Energy Dispersive Spectroscopy
  • SED, Everhart Thornley secondary electron detector.
  • TLD-SE, in-lens secondary electron detector.
  • SS-BSED is a solid-state backscattered electron detector.
  • UHR low vacuum SED (Helix detector)
  • Low vacuum solid-state BSED (GAD)
  • IR camera, Integrated Infra-Red inspection camera

Apply, book and follow your data in one place.

With the embion portal you are able to track your data live from any location no matter what you process your data with.

  • Apply for instrument time

    Applications for instrument time go through the portal for an easy and collaborative workflow.

  • Book sessions

    See the instrument calendar and your upcoming sessions in one place.

  • Follow your data live

    Track your data collections live from any location, no matter what you process your data with.

  • Billing and invoices

    Follow usage and invoices for your group alongside the work itself.

The EMBION portal, shown with illustrative data.

The EMBION portal home: items needing attention, upcoming bookings, running data collections and latest applications

Research at this level is not possible without funding

A DKK 215 million grant from the Novo Nordisk Foundation is establishing DANCEM, a new national cryo-EM infrastructure. Earlier, a 30.8 mio DKK grant from the Ministry of Higher Education and Science brought the Titan Krios to Aarhus, and a Novo Nordisk Foundation grant made cryo-FIB/SEM sample preparation possible.
